CCMT09T304F XPK130

The CCMT09T304F XPK130 is a robust 80° diamond-shaped positive insert built for stability and efficiency. Featuring the chipbreaker, this insert is designed to handle fluctuating depths of cut while maintaining excellent chip evacuation. Paired with the XPK130 grade, it is an industrial powerhouse for steel turning applications.

Key Features:

• Grade XPK130: A high-performance CVD-coated carbide grade. It features an advanced Al2O3 (Alumina) coating layer that provides extreme heat resistance, making it perfect for high-speed dry machining or heavy-duty cuts in Steel (P) and Cast Iron (K).

• Chipbreaker: Engineered for Medium-Roughing. The reinforced cutting edge and wide chip pocket allow for larger chip loads and prevent tool breakage when encountering scale or interrupted cuts.

• Size 09T3: With a thickness of 3.97mm and an IC of 9.525mm, this insert offers significantly more strength and heat dissipation than the smaller 06-size inserts.

• 0.4mm Nose Radius: Provides high precision and sharp cutting action, making it ideal for finishing walls or shoulders while still being strong enough for medium-duty roughing.

• Best For:

  • Medium-duty roughing and semi-finishing of Steel.

  • Applications requiring high heat resistance and stable tool life.

  • Materials: Carbon Steels, Alloy Steels, and Ductile Iron.

  • Fits all standard SCLC style turning tools and boring bars.
